CFM25S-T-power-supply CFM25S-T-power-supply

CFM12S-T Series

CFM12S Series, 12 Watt Chassis Mounting Single Output Power Supplies

Request a quote Download Datasheet

Features

  • Universal Input Range 90~264Vac
  • 1.5”x 1” Open Frame Compact Size
  • No Load Input Power < 75mW
  • Approval IEC/EN/UL 62368-1
  • Approval EN 55032 Class B and CISPR/FCC Class B
  • Operating Altitude 5000m
  • Continuous Short Circuit Protection
  • Chassis Mounting & Encapsulated Versions Available

Models and Ratings

Model Input VAC Output VDC Output Current Size
CFM12S050-T 95~264 5 Volts 2 Amps 38.1 x 25.4 x 19.4mm
CFM12S090-T 95~264 9 Volts 1.34 Amps 38.1 x 25.4 x 19.4mm
CFM12S120-T 95~264 12 Volts 1 Amp 38.1 x 25.4 x 19.4mm
CFM12S150-T 95~264 15 Volts 0.8 Amps 38.1 x 25.4 x 19.4mm
CFM12S240-T 95~264 24 Volts 0.5 Amps 38.1 x 25.4 x 19.4mm
